PCS-V Series

PCS-V Designed for KTV

PCS-V Series KTV Speaker

The PCS-V loudspeaker series is the perfect choice for the Asian KTV market! The PCS-V series loudspeakers consist of two models: PCS-110V and PCS-112V. They utilize a totally newly designed 100° x 40° KTV horn with optimized despertion angle, equipped with rich, clear sound out to 20 KHz, reproducing neodymium driver. The woofers maintain newly designed die-cast chassis and newly formulated paper cone. The specially formulated cone pulp allows this driver to give a warm and smooth response throughout the bass frequency range, which is fantastic! The PCS-V Series is the ideal karaoke loudspeaker system to provide transparent and natural treble, warm and smooth mid-frequency, and powerful bass for clear and elastic drum sounds. The M8 suspension points and 35 mm pole socket offer a wide range of installation and hanging possibilities in both vertical and horizontal orientations, giving you the freedom to choose the perfect setup for your space.

PCS-V10 GS1 (EAN) CODE: 4260318511780

PCS-V12 GS1 (EAN) CODE: 4260318511797

Technical Details

Model Name PCS-V10 PCS-V12
GS1 (EAN) CODE 4260318511780 4260318511797
System Type 1x10“ + 1“ KTV Speaker 1x12“ + 1“ KTV Speaker
Power Rating 300 W AES
600 W program
1200 W peak
350 W AES
700 W program
1400 W peak
Frequency Range (+/- 3 dB) 49 Hz - 20 kHz 41 Hz - 20 kHz
Coverage Pattern (hxv) 100°x40° 100°x40°
Sensitivity 99 dB 1w/1m 102 dB 1w/1m
Maximum SPL 128 dB 133 dB
Nominal Impedance 8 Ohm 8 Ohm
Input Connectors 2 x Neutrik NL4
Socket parallel 1+/1-
2 x Neutrik NL4
Socket parallel 1+/1-
Housing Birch Multiplex Birch Multiplex
Suspension/Mounting 35 mm pole socket
19 x M8 suspension
VSL mounting base
35 mm pole socket
19 x M8 suspension
VSL mounting base
Coating Anti-scratch black coatingg Anti-scratch black coating
Dimensions (h/w/d) 550x330x313 mm 630x385x342 mm
Net weight 18,5 Kg 23,8 Kg
